Static Large-Capacity Liquid Nitrogen Storage Tank

Product Overview

The static large-capacity liquid nitrogen storage tank is a cryogenic storage device specifically designed for long-term preservation of laboratory and biological samples. It is suitable for applications that require a stable ultra-low temperature environment and long-term static storage conditions.

This series of storage tanks features an optimized vessel structure and insulation system, enabling large storage capacity while effectively reducing liquid nitrogen consumption. As a result, it provides a stable and reliable cryogenic environment for long-term sample preservation.

The tank is manufactured from high-strength lightweight aluminum alloy, offering both durability and reduced weight for convenient laboratory use and management. The interior is equipped with a dedicated sample rack system, allowing organized sample storage and efficient retrieval. In addition, an optional intelligent monitoring system can be configured to enable remote monitoring of parameters such as liquid level and temperature.

Working Principle

The static large-capacity liquid nitrogen storage tank maintains an ultra-low temperature environment through a high-efficiency vacuum insulation structure. Multiple insulation layers are installed between the inner and outer walls of the tank, forming a high-vacuum insulation layer that significantly reduces heat transfer from the external environment and lowers the evaporation rate of liquid nitrogen.

As the stored liquid nitrogen naturally evaporates, it generates a stable low-temperature gaseous environment inside the container. This process ensures that the interior remains at extremely low temperatures, providing reliable long-term cryogenic preservation conditions for biological samples.

The tank is equipped with a dedicated internal sample rack system that allows categorized storage and efficient management of samples while maintaining a stable cryogenic environment during retrieval. A safety lock lid design helps prevent unauthorized access and improves overall sample management security.

Key Features

• High-strength lightweight aluminum structure combining durability with reduced weight
• Low liquid nitrogen consumption for long-term stable cryogenic storage
• Uniform internal temperature distribution suitable for long-term sample preservation
• Safety lock lid design to prevent unauthorized sample access
• Equipped with dedicated sample racks for organized storage and efficient management
• Optional intelligent monitoring system for remote operation monitoring
• Reliable vacuum insulation system providing long-term thermal performance

Applications

• Biological Sample Banks:Used for long-term cryogenic preservation of cells, tissues, blood samples, DNA, and other biological materials.
• Medical Research Institutions:Suitable for sample storage and management in medical research and clinical studies.
• Life Science Laboratories:Applied in cell culture, genetic research, and biological experiment sample storage.
• Biotechnology Industry:Used for cryogenic storage of vaccine samples, biological preparations, and research materials.
• Research Institutions:Provides stable cryogenic storage conditions for long-term scientific research and sample studies.
