Liquid Helium Vacuum Insulated Pipe

Product Overview

The Liquid Helium Vacuum Insulated Pipe is a high-performance cryogenic pipeline designed for the transfer of liquid helium. It is widely used in air separation, gas processing, aerospace engineering, electronic equipment, superconducting systems, semiconductor manufacturing, automated assembly, food and beverage processing, pharmaceuticals, medical facilities, biobanks, advanced materials, and chemical industries.

This pipeline is commonly applied for cryogenic media transfer between low-temperature equipment and systems, such as cryogenic storage tanks, Dewar vessels, and cold boxes. As an upgraded alternative to conventional insulated pipelines, it significantly reduces evaporation losses of cryogenic media during transfer, improving system efficiency and operational reliability.

Working Principle

The liquid helium vacuum insulated pipe adopts a high-vacuum multi-layer multi-shield insulation structure. Multiple layers of insulation composite materials are placed between double-layer stainless steel pipes, while maintaining a high-vacuum environment.

This design effectively suppresses heat conduction, convection, and radiation, greatly minimizing external heat ingress into the pipeline. As a result, the heat leakage is only about 0.035–0.05 times that of traditional insulated pipelines, significantly improving cryogenic insulation efficiency and reducing energy consumption.

Key Features

• Ultra-Low Heat Loss:High-vacuum multi-layer insulation structure significantly reduces heat leakage and ensures excellent cryogenic insulation performance.
• Energy Efficient:Heat leakage is only 035–0.05 times that of conventional insulated pipelines, effectively reducing energy consumption.
• Durable Structure:Manufactured from high-quality stainless steel capable of withstanding extreme low temperatures and pressure conditions.
• Stable Operation:Reliable structural design supports long-term continuous operation in cryogenic systems.
• Strong System Compatibility:Can be connected with various cryogenic equipment and pipeline systems, enabling easy engineering integration.

Applications

• Air Separation Systems:Air separation units and cryogenic gas processing equipment.
• Aerospace Engineering:Cryogenic media transfer in aerospace equipment and superconducting electronic systems.
• Semiconductor Manufacturing:Cryogenic processes in chip manufacturing and automated assembly systems.
• Food & Pharmaceutical Industry:Cryogenic processing equipment in food, beverage, and pharmaceutical production.
• Medical & Life Sciences:Hospital cryogenic equipment and biological sample storage systems.
• Industrial Cryogenic Engineering:Cryogenic storage and transfer systems used in advanced materials, rubber, and chemical industries.
• Scientific Research:Low-temperature physics research and cryogenic experimental facilities.
